Structured Networking Solutions
Managed networking solutions encompass the design, installation, and maintenance of network infrastructure using both active and passive components. This includes Fiber optic cabling and splicing, CAT6 structured cabling, IO punching, RJ45 crimping, rack mounting, cable dressing, systematic numbering, and thorough documentation for efficient network management and troubleshooting.
| Component | Description | Office Example |
|---|---|---|
| Entrance Facilities | Where external service provider’s lines enter the building; includes demarcation points and protections. | Internet Service Provider (ISP) Fiber/copper line entry and surge protection panel. |
| Equipment Room | Central room housing major network devices like switches, routers, and servers. | Server room with main racks containing core switches, routers, and backup servers. |
| Backbone Cabling | High-capacity cabling connecting equipment rooms and telecommunication rooms—supports data transfer between floors or buildings. | Fiber optic cables running vertically between floors in a multi-story office. |
| Telecommunications Room | A dedicated room or closet on each floor for network distribution hardware. | Network closet with patch panels and switches serving a specific floor. |
| Horizontal Cabling | Cabling that runs from telecom room to individual work areas on the same floor. | CAT6 cables running from the floor’s network closet to each employee’s desk. |
| Work Area | Area where users connect end devices (PCs, phones) to network outlets. | Wall faceplates with Ethernet ports at employee workstations |
